ASUS P5W64 WS Professional - motherboard - ATX - LGA775 Socket - i975X Series

ASUS P5W64 WS Professional - motherboard - ATX - LGA775 Socket - i975X Series

$199.99 USD
$199.99 USD
Sale Sold out
Used and tested working.

SPECS

GENERAL

  • Chipset Type
    Intel 975X Express / Intel ICH7R
  • Compatible Processors
    Pentium 4, Celeron D, Pentium Extreme Edition, Pentium D, Core 2 Duo, Core 2 Extreme
  • Processor Socket
    LGA775 Socket
  • Max Bus Speed
    1066 MHz
  • Max Processors Qty
    1
  • Manufacturer
    Asus

EXPANSION / CONNECTIVITY

  • Expansion Slots
    1 x CPU
    4 x DIMM 240-pin
    4 x PCIe x16
    2 x PCI
  • Storage Interfaces
    Intel ICH7R: SATA-300 -connectors: 4 x 7pin Serial ATA - 4 devices - RAID 0 / RAID 1 / RAID 10 / RAID 5
    Intel ICH7R: ATA-133 -connectors: 1 x 40pin IDC - 2 devices
    SATA-300 -connectors: 3 x 7pin SATA - 3 devices - RAID 0 / RAID 1 / RAID 10
    SATA-300 -connectors: 1 x 7pin external SATA - 1 devices
  • Internal Interfaces
    1 x audio - 4 pin MPC
    1 x floppy
  • Additional Connectors (Optional)
    2 x IEEE 1394 (FireWire), 4 x USB 2.0
  • Power Connectors
    24-pin main power connector, 8-pin ATX12V connector

PROCESSOR

  • Max Supported Qty
    1
  • Installed Qty
    0

INTERFACE PROVIDED

  • Type
    storage
  • Interface
    Serial ATA-300
  • Qty
    1, 2, 4
  • Connector Type
    7 pin external Serial ATA
  • Type
    LAN (Gigabit Ethernet), PS/2 keyboard, PS/2 mouse, SPDIF out, TOSLINK, USB 2.0, audio line-in, audio line-out, audio line-out (center/subwoofer), audio line-out (rear), audio line-out (side surround), microphone, parallel
  • Connector Type
    mini-jack

NETWORKING

  • Data Link Protocol
    Ethernet, Fast Ethernet, Gigabit Ethernet
  • Network
    2 x Gigabit Ethernet

PROCESSOR / MEMORY / STORAGE

  • Max Supported Qty
    1

CACHE MEMORY

  • Type
    none

MISCELLANEOUS

  • Compliant Standards
    Plug and Play, RoHS
  • Microsoft Certifications
    Certified for Windows Vista
  • Product Type
    motherboard

AUDIO

  • Audio Codec
    AD1988B
  • Compliant Standards
    High Definition Audio

VIDEO

  • Video Output
    none

AUDIO OUTPUT

  • Sound Output Mode
    7.1 channel surround
  • Compliant Standards
    High Definition Audio
  • Type
    sound card
  • Audio Codec
    AD1988B
  • Audio
    High Definition Audio (8-channel)

RAM

  • Max Supported Size
    8 GB
  • Features
    dual channel memory architecture

LAN

  • Network Interfaces
    2 x Gigabit Ethernet

SUPPORTED RAM

  • Bus Clock
    800 MHz, 667 MHz, 533 MHz
  • Features
    Dual channel memory architecture
  • Registered or Buffered
    Unbuffered
  • Speed
    PC2-6400, PC2-5300, PC2-4300
  • Technology
    DDR2
  • Max Size
    8 GB
  • Supported RAM Integrity Check
    Non-ECC, ECC

HEADER

  • Brand
    ASUS
  • Product Line
    ASUS
  • Model
    P5W64 WS Professional
  • Packaged Quantity
    1
  • Compatibility
    PC

MAINBOARD

  • Form Factor
    ATX
  • Processor Socket
    LGA775 Socket
  • Compatible Processors
    Celeron D, Core 2 Duo, Core 2 Extreme, Pentium 4, Pentium D, Pentium Extreme Edition
  • Data Bus Speed
    1066 MHz
  • Chipset Type
    Intel 975X Express
  • I/O Controller
    Intel ICH7R
  • Supported RAM Technology
    DDR2 SDRAM
  • Supported RAM Speed
    533 MHz, 667 MHz, 800 MHz
  • Supported RAM Standard
    PC2-4300, PC2-5300, PC2-6400
  • Supported RAM Integrity Check
    ECC, non-ECC
  • Supported RAM (Registered or Buffered)
    unbuffered
  • Power Connectors
    24-pin main power connector, 8-pin ATX12V connector

MAINBOARD FEATURES

  • BIOS Type
    AMI
  • BIOS Features
    ACPI 2.0 support, ASUS EZ Flash 2, ASUS MyLogo2, ASUS O.C. Profile, Multilingual BIOS, SMBIOS 2.3 support, WfM 2.0 support
  • Sleep / Wake Up
    wake on LAN (WOL), wake on ring (WOR)
  • Manual Settings
    CPU frequency, PCI Express x16 slot frequency, memory voltage, processor core voltage
  • Hardware Features
    ASUS AI Clock Skew, ASUS AI Gear, ASUS AI NOS (Non-delay Overclocking System), ASUS AI Nap, ASUS SATA on the Go, C.P.R. (CPU Parameter Recall), CrashFree BIOS 3, Green Edition, Stack Cool 2, chassis intrusion detection, heat pipe chipset cooling, jack retasking

INTERFACES

  • Storage
    ATA-133, Serial ATA-300 (RAID)

EXPANSION SLOTS

  • Total Qty
    1, 2, 4
  • Type
    CPU, DIMM 240-pin, PCI, PCIe x16

DIMENSIONS & WEIGHT

  • Width
    12 in
  • Depth
    9.6 in

SERVICE & SUPPORT

  • Type
    3 years warranty

STORAGE INTERFACES

  • Chip
    Intel ICH7R
  • Interface
    ATA-133, Serial ATA-300
  • Connector(s)
    1 x 40pin IDC, 1 x 7pin external SATA, 3 x 7pin Serial ATA, 4 x 7pin Serial ATA
  • Supported Devices Qty
    1, 2, 3, 4
  • RAID (Level)
    RAID 0 / RAID 1 / RAID 10

SERVICE & SUPPORT DETAILS

  • Type
    limited warranty
  • Full Contract Period
    3 years

INTERNAL INTERFACES

  • Type
    audio, floppy
  • Connector Type
    4 pin MPC
  • Qty
    1

FEATURES

  • Manual Settings
    CPU frequency, processor core voltage, memory voltage, PCI Express x16 slot frequency
  • BIOS Type
    AMI
  • Hardware Features
    Chassis intrusion detection, C.P.R. (CPU Parameter Recall), jack retasking, Green Edition, ASUS AI NOS (Non-delay Overclocking System), Stack Cool 2, ASUS SATA on the Go, heat pipe chipset cooling, ASUS AI Gear, ASUS AI Nap, ASUS AI Clock Skew, CrashFree BIOS 3
  • BIOS Features
    WfM 2.0 support, Multilingual BIOS, ASUS MyLogo2, ACPI 2.0 support, SMBIOS 2.3 support, ASUS EZ Flash 2, ASUS O.C. Profile
  • Sleep / Wake Up
    Wake on LAN (WOL), wake on ring (WOR)

GENERAL

  • Manufacturer
    Asus
