| Dimensions |
155.6 x 77.9 x 16.5 mm |
| Weight |
260 g (w/ standard battery)
330 g (w/ extended battery) |
| Display |
5" HD (1280 x 720) |
| OS |
Android 6.X
Windows 10 IoT Mobile Enterprise |
| CPU |
1.2 GHz Quad Core Processor |
| Memory |
2GB RAM / 16GB Flash
2GB RAM / 32GB Flash (Optional) |
| Communication |
WPAN: Bluetooth 4.1 BLE, Class 1
WLAN: 802.11a/b/g/n/d/h/i
WWAN: (Optional) LTE, UMTS/HSDPA/HSUPA/HSPA/HSPA+, GSM/GPRS/EDGE
Satellite(for WWAN only):
A-GPS, GLONASS, BeiDou |
| Data Capture |
Scanning : 1D/2D imager
Camera : 13 MP Autofocus with flash (rear), 2.0 MP Fixed Focus (front),
Fingerprint Scanner : Capacitive / Optical
NFC : (Optional) ISO 14443 Type A &B, ISO 15693, MiFare |
| Battery |
3.8V, 3,200 mAh (standard)
3.8V, 6,400 mAh (extended) |
| Drop Spec |
Multiple 1.2m / 4 ft. to tile over concrete at room
temperature |
| Tumble Spec |
1000 1.6 ft./0.5 m tumbles;
meets and exceeds IEC tumble specification |
